Technical Optimization: Through designs incorporating soft-switching technology and line-frequency isolation transformers, the impact of load fluctuations during power-on and power-off on the circuit is minimized, high-frequency interference is suppressed, and system stability is enhanced.
Efficiency Performance: Some products achieve conversion efficiencies of 90–92% under half-load conditions, effectively reducing power loss. Since electricity is billed at single-phase rates, this saves users long-term operating costs.
Designed to meet the demands of complex environments and long-term use, our single- and three-phase amplifiers excel in protection and thermal management:
Protection Rating: IP54 dust- and water-resistant design (select models) enables indoor and outdoor installation, withstands wind and rain, and extends equipment lifespan.
Thermal Management: Intelligent air-cooling architecture ensures stable operation under high-temperature or high-load conditions.
Protection Features: Integrated multiple protections including overcurrent, overload, undervoltage, overvoltage, short circuit, and overheat protection, as well as hard-switch protection for both input and output.
Remote Monitoring: Supports communication protocols such as RS485, Modbus RTU, and CAN, enabling real-time monitoring of DC input/output voltage, current, power status, and more.
Modular Design: Plug-and-play structure reduces maintenance costs.
| Model | SPVLI-30KWH-INV15KW | |
| Isolation mode | Low Frequency Transformer | |
| Inverter Part | ||
| Battery Input | Rated Voltage (Vdc) | 307VDC |
| Voltage range (Vdc) | 278-400V | |
| AC Output | Rated output power | 15KW |
| Output waveform | Pure Sine Wave | |
| Rated Voltage | 380VAC | |
| Phases | 3 phase + N + PE | |
| Rated current (A) | 22.7A(Phase Current) | |
| Frequency | 50/60Hz | |
| Power Factor (PF) | >0.95 | |
| Inverter Efficiency | >92% | |
| Display | LCD+LED | |
| Overload Ability | 120%, 35 seconds | |
| AC-DC Charger Part | ||
| AC Input | Voltage range(Vac) | 180-240Vac |
| DC Output | Rated voltage(Vdc) | 307Vdc |
| Rated current(A) | 20A | |
| Lithium Battery Part | ||
| Cell/Number | 105AH/96PCS | |
| Rated voltage | 307V | |
| Max charge current | 20A | |
| Max discharge current | 100A | |
| Protection Function | Input reverse polarity, under voltage, over voltage, output over-current, short circuit, overheating etc. | |
| Degree of protection | IP20(indoor) | |
| Weight (Kg) | 378Kg | |
The system achieves a high conversion efficiency of 90–92% under half-load conditions, which helps in significantly reducing energy loss and operating costs.
The system utilizes a Low Frequency Transformer for isolation, which provides enhanced stability and suppression of high-frequency interference.
Yes, it supports multiple communication protocols including RS485, Modbus RTU, and CAN, allowing for real-time monitoring of voltage, current, and power status.
The unit includes comprehensive protection against overcurrent, overload, undervoltage, overvoltage, short circuits, and overheating, for both input and output stages.
While the standard model is IP20 rated for indoor use, select models offer an IP54 protection rating, making them resistant to dust and water for outdoor environments.
The inverter provides a Pure Sine Wave output, ensuring compatibility and stable performance for sensitive electronic equipment.
