High-Quality Mobile on-board energy storage system Suppliers, Exporter

Mobile on-board energy storage system is an efficient and flexible energy reserve equipment. It usually consists of a lithium battery pack, a BMS management system, an AC-DC charging device and other components, and is characterised by high energy density, long life, fast charging and high safety. The system provides continuous power supply for electric vehicles. The mobile on-board energy storage system is widely used in the field of emergency energy supply, such as disaster rescue, important occasions to maintain power supply, etc., to ensure that the power needs of key facilities and rescue equipment are met. It is mobile, flexible and easy to operate.

Send Inquiry

Product Description

Product Advantages

All-in-One Design High integration and space-saving installation for maximum efficiency.

High Performance Utilizes lithium iron phosphate (LFP) cells with laser welding for consistency and a 10+ year service life.

Intelligent BMS Features NXP (USA) automotive-grade chips with strong anti-interference and wide temperature range reliability.

Safety Control Independent charge and discharge control ensures system stability even during over-charge or over-discharge events.

Smart Management Master-slave mode with passive equalization and insulation leakage detection for enhanced safety.

Real-time Communication CAN2.0 interface provides strong real-time performance and anti-electromagnetic interference.

Product Parameter

Model		SPVLI-30KWH-INV12KW
Isolation mode		Low Frequency Transformer
Inverter Part
Battery Input	Rated Voltage (Vdc)	307VDC
Battery Input	Voltage range (Vdc)	278-400V
AC Output	Rated output power	12KW
	Output waveform	Pure Sine Wave
	Rated Voltage	120/240VAC
	Phases	Split phase + N + PE
	Rated current (A)	50A(Phase Current)
	Frequency	60Hz
	Power Factor (PF)	>0.95
	Inverter Efficiency	>92%
	Display	LCD+LED
	Overload Ability	150%, 35 seconds
AC-DC Charger Part
AC Input	Voltage range(Vac)	180-240Vac
DC Output	Rated voltage(Vdc)	330Vdc
DC Output	Rated current(A)	20A
Lithium Battery Part
Cell/Number		105AH/96PCS
Rated voltage		307V
Max charge current		20A
Max discharge current		100A
Protection Function		Input reverse polarity, under voltage, over voltage, output over-current, short circuit, overheating etc.
Degree of protection		IP20(indoor)
Mechanical Dimension		645x891x767mm / 378Kg

Applications

Power Quality Management

Improve power quality of distribution networks and solve voltage fluctuations or frequency instability.

New Energy Access

Balance the intermittency and instability of renewable energy generation as a reliable storage device.

Temporary Charging Points

Quickly deploy as temporary charging stations for electric vehicles during peak demand periods.

Backup & Emergency Power

Provides continuous power supply for critical sites during outages, disasters, or rescue operations.

Outdoor Activities

Reliable power support for camping, hiking, and outdoor events for lighting, audio, and charging.

Frequently Asked Questions

What is the total capacity and power output of the SPVLI-30KWH model?

The system features a 30kWh energy capacity with a 12KW rated output power, suitable for heavy-duty applications.

What kind of batteries are used in this system?

The system uses high-performance lithium iron phosphate (LiFePO4) cells, known for safety and a long service life of over 10 years.

Does the system support split-phase power for North American standards?

Yes, it supports Split phase (120/240VAC) + N + PE, making it compatible with various regional electrical requirements.

How does the system handle extreme temperatures?

It includes integrated cell temperature management that can link with air conditioners or heaters to ensure the battery operates at its ideal temperature range.

Is this system suitable for indoor use?

Yes, the system has an IP20 protection rating, specifically designed for indoor installation and protection.

What safety certifications or protections are included?

The system includes protection against input reverse polarity, under/over voltage, output over-current, short circuits, and overheating, managed by an automotive-grade BMS.
